CR26500 Li-MnO2 Battery High Power Type
The Applications of CR26500 Power Type
Water, gas and electricity meters,Alarm system, GPS system, GSM system, Medical devices, Intelligent IC Meter, Marine equipment, Portable devices, ELTS, EPIRBS, etc.
CR26500 Power Type Battery Basic Specifications
CR26500
Nominal Capacity: 5400mAh
Nominal Voltage:3.0V
Standard Discharge Current: 1mA
Max. Continuous Discharge Current: 2000mA
Max. Pulse Discharge Current: 3000mA
Discharge Cut-off Voltage: 2.0V
Weight: Approx. 62g
Operating Temperature: -40~85℃
Storage Condition: Temperature ≤ 30℃; Humidity ≤ 75%RH
CR26500 Power Type Battery Features:
High Voltage: 3.0V per cell
Spiral electrode structure ensures high-rate current discharge
Low self-discharge rate and long shelf life
Applicable in a wide temperature range
Operational temperature range:
Hermetically glass to metal sealed type: -40℃ to +85℃
Consult EEMB when using batteries at temperatures beyond or below the -40℃ to +85℃ range
Stable discharge characteristics
Superior leakage resistance
