3.7V 700mah 16340 li-ion rechargeable cylindrical battery cell battery
16340 3.7v 700mah Battery Features:
High working voltage:Working voltage is up to 3.7V.
High Power Density:Advanced technology provides ultra-high capacity performance rechargeable Li-ion batteries .
Wide Operating Temperature Range. LIR 18650 Li-ion batteries can be charged over a temperature range of 0°C to 45°C, and discharged between -20°C to 60°C.
High-Output and High-Load Characteristics.Continuously discharge rate is 2C.
Safe and Reliable:All batteries are equipped with multiple safety features, including safe shut-down separator and safety vent.
Long Cycle Life.
Low self-discharge rate.
No memory effect:No memory effect assures a constant maximum application.
The Applications of 16340 3.7v 700mah
Usage 1: notebook battery core replacement, high-grade strong light flashlight, mobile power supply, electronic cigarette, scanning gun, card swiping POS machine.
Application 2: PHS telephone, walkie talkie, Bluetooth audio, portable fax machine, printer, digital camera, camera.
Application 3: portable DVD, VCD, electric motorcycle power supply, electric bicycle power supply, electric drill, electric planer, medical equipment, etc.
16340 3.7v 700mah Battery Basic specifications
Nominal voltage | 3.7 V |
Nominal capacity | 700mAh |
discharge from 4.2V to 3.0V at 0.2C mA | |
Minimal capacity | 700mAh |
Max charge current | 700 mA 1C |
Charging method | charge with constant current 1C to 4.2V, then charge with constant voltage 4.2V till charge current is less than 0.01C |
Discharge cut-off voltage | 3.0 V, the over-discharge detection voltage of PCM |
Operating environment | Charging, 0°C ~ 45°C ; 65±20%RH |
Discharging, -20°C~60°C ; 65±20%RH | |
Storage environment | -20°C~45°C |
storage for a long time(>3 months) and the storage condition shall be:<35°C;65±20%RH;3.7~3.9V | |
Cell Weight (Approx) | 23g |
Cell Dimension (Max) | according to customer demand |
